Ball indenter for Rockwell test, 1,5875mm tungsten carbide ball

without calibration certificate

Item number: 11AAD465

Mitutoyo indenters for Rockwell hardness test

As the interface between machine and material, the indenter must be of immaculate quality.
Therefore Mitutoyo only uses diamond indenters from the most experienced suppliers.
The indenters are calibrated in the highest standard calibration laboratories in the DAkkS accreditation body, accredited according to ISO 17025 and traceable to the PTB.
Constant development at our calibration partners secures an unmatched quality level.

Rockwell diamond indenter feature DAkkS calibration certificates according to DIN EN ISO 6508-2 and/or ASTM E18.
A function test, verifying the applicability of the indenter in regard of various indentation depth levels under different test forces, is optionally available.

Ball holders are made by Mitutoyo, and are supplied without calibration certificate for the included ball.
Please order a calibrated ball separately.
Function tests for ball holders are available on request.

Please contact us if you do not find what you are looking for.

Description:	Rockwell ball indenter with 1,5875mm 1/16" tungsten carbide ball. Calibration certificate not included.
Method:	Rockwell
Type:	Ball indenter
Material:	tungsten carbide
Ball Diameter mm:	1.5875
Ball Diameter Inch:	1/16"
Calibration:	without
Shaft Ø mm:	6.3
Shaft length:	11
Chamfer angle°:	20
Collar Ø mm:	10
Usable length mm:	15.9
Total length mm:	26.9
Product line:	HR-100 HR-200 HR-300 HR-400 HR-500 HR-600 AR-10, AR-20 ARK
