2-Point Inside Measuring Instrument Range 7-10mm Graduation .01mm 526-126

MitutoyoSKU: 526-126

List price: Regular price£371.00 Offer price: Sale price£260.00 Excluding VAT

Optional Services

Price is per item. Add your Gauge ID, asset number or company name.
£10.00 per item

Please check before engraving: New gauges engraved to your requirements cannot be returned for credit if ordered incorrectly or no longer required. Please confirm the gauge specification and marking details before ordering. This does not affect your rights if the goods are faulty or incorrectly supplied.

This is a two point split contact point ideally suited to smaller bore measurements.
It offers you the following benefits:
  • A precision bore gauge so you can make quick and accurate measurements of small hole diameters (0.95-18 mm).
  • You can replace the analogue indicator fitted to this instrument with a customer-supplied Digimatic indicator if you need.
  • The contact point is hard chrome coated.
Inch-Metric:
Metric
Digital/Analog:
Analog
Range:
7 - 10 mm
Graduation:
0.01mm
Accuracy:
4 µm
Repeatability:
2 µm
Measuring depth:
40-56 mm (2)
No. Dial Indicator:
2046AB
Number of anvils:
6
Delivered:
In a box, with dial indicator and cover for dial indicator, without setting ring
Mass:
300 g

No technical information is currently available.

No application information is currently available.
