375-056 Calibration Micro Scale

By installing this system on the camera mount of an MF series measuring microscope and
projecting the focusing chart onto the workpiece surface, you can detect the focal point with high accuracy and high repeatability.
The Focus Pilot FP-05 / FP-05U offers you the following benefits:

• You can easily adjust the brightness of the image.
• You can achieve a wide view field observation on the monitor using a CCD camera (a C-mount adapter is included).
• You are offered a choice of four chart patterns, so you can select the pattern that works best with your workpiece surface texture type.
