| Inch-Metric: |
Inch
|
| Reference length : |
1, 2, 3, 4, 5, 6"
|
| Range: |
0 - 6 "
|
| Anvil block accuracy: |
±0.5 µm
|
| Block pitch accuracy: |
±(40+L/0,15)µin L= lenght to check (inch)
|
| Delivered: |
In a wooden case with certificate of inspection, 1" carbide reference block
|
| Mass: |
3 kg
|
No technical information is currently available.
No application information is currently available.
