Baker (Mercer Style) Plunger indicator K08, Range 25mm, Graduation .01mm, Reading 0-100

Name: Baker (Mercer Style) Plunger indicator K08, Range 25mm, Graduation .01mm, Reading 0-100
Brand: Baker
SKU: K08
Price: 39.0 GBP
Availability: InStock

BakerSKU: K08

All prices exclude VAT, which will be added at checkout.

Price:

£39.00 £65.00

Quantity:

A sturdy and robust dial gauge.
Fitted with special brass bush bearings.
Supplied with tolerance pointers.
Strong and smooth metal bezel.
Rigid, metal case.
Aesthetically appealing protective top cap.
Tungsten carbide ball anvil.
Metric gauges conform to IS2092-1983 and for the European market to DIN878-1983.
Inch gauges conform to ASME B89.1.10M-2001.
Each gauge carries a calibration certificate giving actual values.
Wide range of dial gauges in various ranges and readings available.
Special dial gauges for OEMs also manufactured on request.
Complete spares and after sales service available.

Baker (Mercer Style) Plunger indicator K08, Range 25mm, Graduation .01mm, Reading 0-100

Vendor	Baker
Part Number	K08
Type	Standard Indicators 57mm Series 2, Metric
Graduation	.01mm
Unit of Measurement	Metric
Measuring Range	25mm
Dial Face Size Ø	57mm
Measuring Force	2 N
Dial Reading	0-100
Range Per Rev	1mm
Back	Centre Lug Back
Repeatibility	.005mm
Hysteresis	.003mm
Dial Indicator Accuracy	.015mm
Repeatability	.003mm
Contact point Thread	M2 x .45mm

Menu

Baker (Mercer Style) Plunger indicator K08, Range 25mm, Graduation .01mm, Reading 0-100

Description

Related Products

Recently viewed

Product Information
Part Number	K08
Measuring Ranges	25mm
Graduation	.01mm
Accuracy	0.3mm
Unit of Measurement	Metric
Measuring Force	≤2.5N
Repeatability	.005mm
Dial Reading	0-100
Dial Face Size Ø	57mm
Hysteresis	.005mm
Stem	8mm
Stem Diameter	8mm
Back	Centre Lug Back
Range Per Rev	1mm
Manufacturer	Mitutoyo
