Chotest Universal Thread Measuring Machine SJ5500

1) Leading high-speed multi-channel, high-precision linear encoder system: The resolution of linear encoder is up to 0.01um and its
repeatability is less than 0.1um.
2) Accurate control system of measuring force: Stable and reliable contact measurement is achieved by accurate control system of
measuring force, in addition, error resulted from unstable measuring force is reduced. Its measuring force is much less than the one
of similar machine from other company. The small measuring force helps to improve duration of Measuring probe(more than 10,000
times), as well as avoid scratching the gauges.
3) Precision air-bearing guide rail system: Master key manufacturing technology of precision air-bearing guide rail system with no
wear, micro friction.
4) Special manufacture of key part: Measuring values are acquired truly and accurately by using high-rigid and deformation-free
Measuring probes made from imported special materials
5) Ingenious balance arm technology: it eliminates swing of guide rail, which ensures orthogonal stability of coordinate system in
measurement.
6) Precision mechanical design experience and manufacturing, assembling ability: The company has been designing and
manufacturing precision instruments for more than 10 years; A number of R & D engineers who have rich experience in the
designning and manufacturing of precision instruments and a group of skilled technicians for machining, assembling ensure
sophisticated producing technology; There are dvanced inspecting, processing equipments in the factory.
3. Simple, humanized design
With quick workholders for thread and user-friendly software UI, without complex adjustment process as well as manual recording,
the operator can be trained to use it within a few minutes. Operation of the machine is extremely simple.
1) Provide user with Simple, practical, fast
operating interface thanks to 10 years
accumulated designing experience in metering
software.
2) With built-in various thread standards, the
software can record and process the data in
measurement, finally generate the test result
automatically.
3) Wide application: can measure most of thread
gauges.
4) User-friendly Russia software system and
simple & convenient operation.
5) Output reports in a variety of formats in Word
or PDF; Can print multiple selected test records or
test certificates from database at the same time
6) All test records can be kept in the database of
computer thanks to large capacity storage
technology.
