Coating thickness gauge - PT-600 -PS Paint Thickness Gauge FE/F/N With Blue Tooth

?DESCRIPTION?

The series of PT-600 coating thickness gauges can be used to measure the thickness of non-conductive coatings on non-ferrous metals and non-magnetic insulating coatings on ferromagnetic metals (such as iron, nickel and cobalt, etc.). They are mainly used for non-destructive thickness measurement for the coatings of paint or galvanized layers on iron and stainless steel, paint or plastic film on aluminum and copper, etc.

PT-600 is with internal probe combined with magnetic induction and eddy currents principle, which is with measuring range of 0~2000?m and accuracy of ±(3%+1?m), and the highest resolution is up to 0.1?m.

PT-600 is only with one button, and it is easy to operate. When you start measurement, place the probe vertically and rapidly on a suitable surface, then the device will automatically distinguish the substrate material and measure the thickness of coatings.

PT-600X optimizes the principle on the basis of PT-600, and uses OLED display to enhance the low temperature working performance. Under the condition of using low temperature resistant battery, the extreme working temperature of PT-600X can reach -50?.

On the basic of PT-600, PT-600S is upgraded its probe and accuracy, and added new functions. The PT-600S is with stronger anti-interference ability compared with PT-600, and it can work in the high electromagnetic fields environment. The accuracy of PT-600S is ±(2%+1?m), and the measurement result can be sent to the mobile APP in real-time via bluetooth.

PT-600SE is with external probe version, the gauge can be equipped with a variety of separated probes for easy replacement. PT-600SE is better suited to work in narrower spaces or on assembly lines compared with PT-600S.

?FEATURES?

· ruby probe

· With Bluetooth and mobile APP (PT-600S/SE)

· Response time up to 0.3 seconds

· Can work in low temperature as low as -40? (PT-600X)

· Resolution up to 0.1?m

· Accuracy ±(2%+1?m) (PT-600S/SE)

· Measuring range 0~2000?m

· Display the maximum, minimum,average and numbers of readings

· Can recall 10 measurements

· One button

· Zero calibration supported

· External probe optional (PT-600SE)

· Dot matrix display

· Automatic shut-down

· Low power protection

?APPLICATION?

· Laboratory physical measurement and recording

· Boiler equipment operation

· Concrete pouring

· Metal processing

· Food

· Medicine

· Household

· Industry, aerospace

· Cold chain transportation

· Car market

· Livestock

· Supermarket
