| Digital/Analog: |
Analog
|
| Inch-Metric: |
Metric
|
| Delivered: |
With certificate of inspection, bezel clamp
|
| Range: |
20 mm
|
| Range per rev.: |
1 mm
|
| Dial reading: |
±0-100
|
| Graduation: |
0,01 mm
|
| MPE first one revolution: |
±10 µm
|
| MPE first 2 1/2 revolutions: |
±10 µm
|
| MPE > 2 1/2-10 revolutions: |
±15 µm
|
| MPE > 10-20 revolutions: |
±20 µm
|
| H MPE (Hysteresis): |
4 µm
|
| R MPE (Repeatability): |
±3 µm
|
| Type: |
ANSI/AGD Standard
|
| Measuring force: |
0,4-2 N
|
| Stem: |
9.52 mm / 0.375"
|
| Contact point: |
Carbide tipped, thread: 4-48UNF
|
