Dial Gauge, Flat Back, ISO Type Jewelled Bearing, 5mm, 0,01mm 1044AB-15

Roll over image to zoom in Click on image to zoom

Dial Gauge, Flat Back, ISO Type Jewelled Bearing, 5mm, 0,01mm 1044AB-15

Name: Dial Gauge, Flat Back, ISO Type Jewelled Bearing, 5mm, 0,01mm 1044AB-15
Brand: Mitutoyo
SKU: 1044AB-15
Price: 70.0 GBP
Availability: InStock

MitutoyoSKU: 1044AB-15

- Free UK delivery on orders over £100

- Fast dispatch from UK stock (over 25,000 gauges in stock)

- UKAS calibration available on all gauges (allow 7 days for calibration)

Price:

£70.00 £96.20

Quantity:

All prices exclude VAT, which will be added at checkout.

Compact Type 5 mm Range Small Diameter - Metric

This is a compact, dial indicator with a bezel ∅ 40 mm. It offers you the following benefits:

It is ideal for use in applications where space is limited.

Product Information
Part Number	1044AB-15
Measuring Ranges	5mm
Resolution	0.01mm
Graduation	.01mm
Accuracy	.013mm
Unit of Measurement	Metric
Measuring Force	≤0.4N
Type	Flat Back
Repeatability	.003mm
Dial Face Size Ø	40mm
Hysteresis	.004mm
Stem	8mm
Back	Flat back
Range Per Rev	1mm
Scale	±0-100
Manufacturer	Mitutoyo

Digital/Analog:	Analog
Inch-Metric:	Metric
Delivered:	With certificate of inspection
Range:	5 mm
Range per rev.:	1 mm
Dial reading:	±0-100
Graduation:	0.01 mm
MPE any 1/10 revolution:	5 µm
MPE any 1/2 revolution:	9 µm
MPE any 1 revolution:	10 µm
MPE measuring range:	12 µm
H MPE (Hysteresis):	3 µm
R MPE (Repeatability):	3 µm
Measuring force:	0,1-0,4 N
Mass:	90 g
Stem:	8 mm
Contact point:	Carbide tipped, thread: M 2.5 x 0.45 mm
Continuous dial:	Yes
Type:	EN ISO Standard
