Zero setting in setting master e. g. according to DIATEST company standard or DIN 2250-C Repeatability (standard split-ball probes): manual gauging ca. 1 ?m, gauging in stand < 0.5 ?m In addition to bore measurement, DIATEST split-ball probes can detect geometrical shape defects such as ovality, concentricity, barrel-shape, etc.
Complete set with Probes, Setting Rings, 1 Needle, 1 Holder in a wooden case.
Inch probes supplied with nominal setting rings:
0.833 -0.880"
0.872 -0.930"
0.922 -0.980"
0.972 -1.036"
1.022 -1.080"
1.072 -1.130"
Dial indicator not included as standard
No technical information is currently available.
No application information is currently available.
