Description
These are three-point internal micrometers that offer you the following benefits:
- Individual micrometer
- Titanium-coated measuring pins give you excellent durability and impact resistance
- They also have excellent resistance against water and dust (IP65 protection level), allowing you to use this product in machining situations that include splashing coolant fluid
- Large LCD display with character height of 7.5 mm enables you to read measurements easily
- Setting rings and extensions available separately – Extension rod: 952622
Bore Gauge Features
- Range: 30.48-40.64mm (1.2-1.6?)
- Resolution: 0.001mm (0.00005?)
- Accuracy: ± 0.003mm (0.00015?)
- Measuring depth: 103.8mm (4.08?)
- Measuring face: Titanium-coated tungsten carbide
- ABSOLUTE & incremental modes
- IP65: High level of protection against liquid and dust ingress
- Data Output
- Data hold
- Zero-setting
- 2 x Preset
All images are for representation only.
No technical information is currently available.
No application information is currently available.
