Digital Indicator Features:
- Range: 0-50mm
- Resolution: 0.0005mm/0.01mm/0.001mm
- Accuracy: 0.003mm
- H MPE (Hysteresis): 0.002mm
- R MPE (Repeatability): 0.002 mm
- Type: EN ISO Standard
- Scale: Electrostatic capacitance type absolute linear encoder
- Max response speed: Unlimited
- Stem diameter: 8mm
- Contact point: Carbide ballm M2.5×0.5
- Switchable resolution
- Data hold
- ABS/INC (INC Zero): Yes
- Digimatic data output
- Inch/Metric
- MPN: 543-857E
- Brand: Mitutoyo
