Mitutoyo Digital Tube Micrometer, Spherical Anvil Inch/Metric, 25-50mm/ 1-2", IP65 395-352-30
Mitutoyo Digital Tube Micrometer, Spherical Anvil Inch/Metric, 25-50mm/ 1-2", IP65 395-352-30
Mitutoyo Digital Tube Micrometer, Spherical Anvil Inch/Metric, 25-50mm/ 1-2", IP65 395-352-30
Mitutoyo Digital Tube Micrometer, Spherical Anvil Inch/Metric, 25-50mm/ 1-2", IP65 395-352-30
Mitutoyo Digital Tube Micrometer, Spherical Anvil Inch/Metric, 25-50mm/ 1-2", IP65 395-352-30
Mitutoyo Digital Tube Micrometer, Spherical Anvil Inch/Metric, 25-50mm/ 1-2", IP65 395-352-30
Mitutoyo Digital Tube Micrometer, Spherical Anvil Inch/Metric, 25-50mm/ 1-2", IP65 395-352-30
Roll over image to zoom in Click on image to zoom
Mitutoyo Digital Tube Micrometer, Spherical Anvil Inch/Metric, 25-50mm/ 1-2", IP65 395-352-30Mitutoyo Digital Tube Micrometer, Spherical Anvil Inch/Metric, 25-50mm/ 1-2", IP65 395-352-30Mitutoyo Digital Tube Micrometer, Spherical Anvil Inch/Metric, 25-50mm/ 1-2", IP65 395-352-30Mitutoyo Digital Tube Micrometer, Spherical Anvil Inch/Metric, 25-50mm/ 1-2", IP65 395-352-30Mitutoyo Digital Tube Micrometer, Spherical Anvil Inch/Metric, 25-50mm/ 1-2", IP65 395-352-30Mitutoyo Digital Tube Micrometer, Spherical Anvil Inch/Metric, 25-50mm/ 1-2", IP65 395-352-30Mitutoyo Digital Tube Micrometer, Spherical Anvil Inch/Metric, 25-50mm/ 1-2", IP65 395-352-30

Mitutoyo Digital Tube Micrometer, Spherical Anvil Inch/Metric, 25-50mm/ 1-2", IP65 395-352-30

MitutoyoSKU: 395-352-30
List price: £543.00 Offer price: £396.00 Excluding VAT

Optional Accessories

Select any accessories you require. Click a part number to view the accessory details.

Micrometer Stand, Adjustable Angle Type 156-101-10
Part number: 156-101-10  → View product
Mitutoyo Micrometer Stand, 45° Angle Type for Micrometer 0-50mm/0-2" 156-105-10
Part number: 156-105-10  → View product
MMI-10 Micrometer Checker on a stand Metric 10-piece Set 2.5, 5.1, 7.7, 10.3, 12.9, 15.0, 17.6, 20.2,22.8 & 25.0 mm
Part number: MMI-10  → View product
MMI-8 Micrometer Checker on a stand Metric Metric 8-pieces set 3.1, 6.5, 9.7, 12.5, 15.8, 19.0, 21.9 & 25.0 mm
Part number: MMi-8  → View product
Mitutoyo 516-106-10 10 Blocks Micrometer Inspection Gauge Block Set Grade 0
Part number: 516-106-10  → View product
U-WAVE fit, IP67 Type Wireless Transmitter for Micrometer/Indicator 264-622
Part number: 264-622  → View product
U-WAVE fit, Buzzer Type Wireless Transmitter for Micrometer/Indicator 264-623
Part number: 264-623  → View product
U-WAVE fit Bluetooth, IP67 Type Wireless Transmitter for Micrometer/Indicator 264-626
Part number: 264-626  → View product
U-WAVE fit Bluetooth, Buzzer Type Wireless Transmitter for Micrometer/Indicator 264-627
Part number: 264-627  → View product
Mitutoyo Connection Unit IP Caliper, Micrometer U-WAVE fit, U-WAVE fit Bluetooth 02AZF310
Part number: 02AZF310  → View product
Mitutoyo Digimatic Cable with Data Button IP Type 05CZA662
Part number: 05CZA662  → View product
Mitutoyo Digimatic Cable with Data Button IP Type 05CZA663
Part number: 05CZA662  → View product
USB Input Tool Direct (Digimatic USB) 06AFM380B
Part number: 06AFM380B  → View product
USB Input Tool Interface Box 264-020
Part number: 264-020  → View product
Statistic Processing Printer DP-1VA Data Printer and Logger BS Type 264-505E
Part number: 264-505E  → View product

Mitutoyo; Digital Tube Micrometer

This Digimatic Tube Micrometer allows you to measure curved
surfaces such as the wall thickness of tubes, bearings and rings.
Specification
Digital/Analog:
Digital
Delivered:
Including box, spanner, setting standard, 1 SR44 battery
Inch-Metric:
Inch/Metric
Range:
1 - 2 "/25-50mm
Digital step:
0,00005"/0,001 mm
Max.
Permissible Error
J MPE:
±0,0001"/.002mm
Flatness:
0,000012"/.003mm
Display:
LCD, character height 7.5 mm
Measuring face:
Carbide-tipped, micro-lap finish
Anvil / Spindle:
Type A, spherical anvil SR=4 mm/flat spindle
Measuring spindle:
With spindle lock, ø6,35 mm, spindle pitch 0,5 mm
Scale:
Thimble and sleeve satin chrome finish, ø18 mm
Measuring force:
5 - 10 N
Power supply:
1 battery SR-44
Battery life:
Approx. 2.4 years
Delivered:
Including box, setting standard (from 25 mm upward), key, 1 battery

No technical information is currently available.

No application information is currently available.

Product Documents

Product Document Mitutoyo Digital Tube Micrometer, Spherical Anvil Inch/Metric, 25-50mm/ 1-2", IP65 395-352-30 Click to open the PDF document
