Wirless data transmission, avoiding errors, efficient and convenient.
Key Features:
- Bluetooth HID direct connection mode: Excel Accessible, Flexible to Mobile phone & Computer.
- Bluetooth BLE: System management of multiple tools.
- Higher efficiency.
- Automatic forms filling avoiding recording errors.
- No more paper records.
Key Features:
- HID Connection: Excel Accessible, flexible to mobile phone/computer.
- BLE Connection: System management of multiple tools.
- Large Screen for easy reading.
- Low power consumption 150 hours of continuous operation.
- Avoid manual transcription errors, 50% efficiency increase.
Specifications:
- Measurement Range: 200mm/8"
- Resolution: 0.01mm/.0005"
- Accuracy: ±0.02mm/±0.001"
- Wireless Mode: Bluetooth 5.0
- Battery: CR2032
- Dimensions: 286×90.5×15.3
- Weight: 190g
Specifications
| Accuracy | ±0.02mm/.001" |
| Resolution | 0.01mm/.0005" |
| Measurement Range | 200mm/8" |
| Work Temperature | 0-40? |
| Battery | CR2032 |
| Working Humidity | ?85%RH |
| Wireless Distance | Bluetooth 5.0 |
| Order No. | Measuring Range | Resolution | Accuracy | L×H×W(mm) |
| I-DCB200 | 200mm | 0.01mm | ±0.02mm | 286×90.5×15.3 |
