- Measuring range: ± 0.3mm
- Measuring force: 0.1N
- Bolt travel: 0.7mm
- Repeatability: 0.0001mm
- Hysteresis: 0.00025mm
- Accuracy (L in mm): 0.2 + 50 x (L x L) µm
- Ball insert: Tungsten carbide Ø2mm
- Cable: 2m
- Housing material: Matt chrome-plated
- IP rating: IP40
- Standard: DIN 32876
