• Micrometer conforms to DIN 863
• Ingress protection rating: IP54 Dust & Splash proof
• Metric/Inch Conversion
• Relative & Absolute Modes
• Hold Function
• Auto power off after 5 minutes
• Auto power up when barrel is turned
• Resolution: Metric: 0.001mm, Inch: 0.00005”
• Accuracy: ±0.002mm
• Repeatability: 0.001mm
• Digit Size: 7mm
• Measuring tips stainless steel
• Friction thimble with solid end drive
• Frame: Non-glare satin chrome finish plus heat guard
• Supplied with setting ring
• Marked with serial number
• Power: 1 x Lithium 3v Batt CR 2032
• Supplied in fitted plastic case complete with adjustment tool
• Ingress protection rating: IP54 Dust & Splash proof
• Metric/Inch Conversion
• Relative & Absolute Modes
• Hold Function
• Auto power off after 5 minutes
• Auto power up when barrel is turned
• Resolution: Metric: 0.001mm, Inch: 0.00005”
• Accuracy: ±0.002mm
• Repeatability: 0.001mm
• Digit Size: 7mm
• Measuring tips stainless steel
• Friction thimble with solid end drive
• Frame: Non-glare satin chrome finish plus heat guard
• Supplied with setting ring
• Marked with serial number
• Power: 1 x Lithium 3v Batt CR 2032
• Supplied in fitted plastic case complete with adjustment tool
Insize 3133-25 Spline Micrometers digital 0-1"/0-25mm
No technical information is currently available.
No application information is currently available.
No videos or documents are currently available.
