Description
- Precise, intuitive to use and digital – with our counting scales you can accelerate your annual stock taking processes and thus save time and money
- Self-explanatory, graphic control panel, the workings steps can be understood immediately, even without operating instructions
- no learning time = reduces costs
- ideal for untrained users
- visualised process avoids operating errors - The 4 steps are carried out from left to right:
[[1]] Place the empty container onto the weighing plate and tare by pressing the TARE key
[[2]] Place the reference quantity for the goods to be counted into the container (5, 10, 20 or any number of pieces)
[[3]] Confirm the selected reference quantity by pressing the key (5, 10, 20 or any number of pieces)
[[4]] Pour in the goods to be counted. The number of pieces will immediately be shown in the display - Precise counting: The automatic reference weight optimisation of reference weight gradually improves the average piece weight value
- KERN Universal Port (KUP): permits the connection of an external KUP interface adapter, such as, for example, RS-232, USB, Bluetooth, WiFi or Ethernet, for the exchange of data and control commands, without any installation outlay
- KERN Communication Protocol (KCP): The KCP permits searching and remote control of the balance using external control devices or computers
- Two balances in one: Changes from counting mode to weighing mode at the touch of a key
- Protective working cover included with delivery
Technical Data
| Weighing capacity [Max] | 65 kg |
| Readability [d] | 0,0002 kg |
| Units | kg, g, gn, dwt, ozt, lb, oz, ffa, PCS |
| Dimensions weighing platform (W×D×H) | 340×240×21 mm |
| Dimensions weighing surface (W×D) | 340×240 mm |
| Reproducibility | 0,0004 kg |
| Linearity | ± 0,001 kg |
| Ambient temperature | -10 °C – 40 °C |
| Smallest piece weight when piece counting - normal conditions | 2 g |
| Display type | LCD |
| Display digit height | 25 mm |
| Material weighing plate | stainless steel |
| Material housing | ABS plastic |
| Tolerance weighing | |
| Net weight approx. | 7 kg |
| Construction type of the scale | Single-range balance |
| GTIN/EAN number | 4045761357495 |
