Description
- Precise, intuitive to use and digital – with our counting scales you can accelerate your annual stock taking processes and thus save time and money
- Self-explanatory, graphic control panel, the workings steps can be understood immediately, even without operating instructions
- no learning time = reduces costs
- ideal for untrained users
- visualised process avoids operating errors - The 4 steps are carried out from left to right:
[[1]] Place the empty container onto the weighing plate and tare by pressing the TARE key
[[2]] Place the reference quantity for the goods to be counted into the container (5, 10, 20 or any number of pieces)
[[3]] Confirm the selected reference quantity by pressing the key (5, 10, 20 or any number of pieces)
[[4]] Pour in the goods to be counted. The number of pieces will immediately be shown in the display - Precise counting: The automatic reference weight optimisation of reference weight gradually improves the average piece weight value
- KERN Universal Port (KUP): permits the connection of an external KUP interface adapter, such as, for example, RS-232, USB, Bluetooth, WiFi or Ethernet, for the exchange of data and control commands, without any installation outlay
- KERN Communication Protocol (KCP): The KCP permits searching and remote control of the balance using external control devices or computers
- Two balances in one: Changes from counting mode to weighing mode at the touch of a key
- Ring-shaped draught shield standard, weighing space ?×H 90×40 mm
- Protective working cover included with delivery
-
-
Technical Data
Weighing capacity [Max] 360 g Readability [d] 0,001 g Units kg, g, gn, dwt, ozt, lb, oz, ffa, PCS Dimensions weighing surface (Ø) 82 mm Reproducibility 0,001 g Linearity ± 0,005 g Ambient temperature -10 °C – 40 °C Smallest piece weight when piece counting - normal conditions 20 mg Display type LCD Display digit height 25 mm Material weighing plate plastic Material platform stainless steel Material housing ABS plastic Tolerance weighing Net weight approx. 0,85 kg IP protection - complete device - Construction type of the scale Single-range balance GTIN/EAN number 4045761243439
No technical information is currently available.
No application information is currently available.
