Linear Scale AT715 100mm/4" Coolant Proof IP67 Absolute Linear Scales 539-801R

Roll over image to zoom in Click on image to zoom

Linear Scale AT715 100mm/4" Coolant Proof IP67 Absolute Linear Scales 539-801R

Name: Linear Scale AT715 100mm/4" Coolant Proof IP67 Absolute Linear Scales 539-801R
Brand: Mitutoyo
SKU: 539-801R
Price: 308.0 GBP
Availability: InStock

MitutoyoSKU: 539-801R

- Free UK delivery on orders over £100

- Fast dispatch from UK stock (over 25,000 gauges in stock)

- UKAS calibration available on all gauges (allow 7 days for calibration)

Price:

£308.00

Quantity:

All prices exclude VAT, which will be added at checkout.

This linear scale is based on electro magnetic induction principle thus offering you high environment protection IP level, in the mean time reference point is not necessary after each power on.

Only compatible with KA series display units.

Product Information
Part Number	539-801R
IP Rating	IP67
Type	AT715
Detection Method	Electromagnetic induction
Maximum Response Speed	50m/min

Measuring method:	Electromagnetic induction system
Accuracy:	100 to 500 mm ±5 µm 600 to 1800 mm ±7 µm 2000 to 3000 mm ±10 µm
Max. drive speed:	50 m/min
Signal period:	20 µm
Resolution:	0,001 / 0,005 (switchable via Counter)
Cable length:	3.5 m
