| Digital/Analog: |
Analog
|
| Delivered: |
In a paper box with spanner 200154
|
| Inch-Metric: |
Metric
|
| Range: |
0 - 25 mm
|
| Graduation: |
0.001 mm
|
| Max. Permissible Error J MPE: |
±2 µm
|
| Spindle end: |
Flat
|
| Spindle pitch: |
0,5 mm
|
| Stem Ø: |
12 mm
|
| Stem: |
w/ clamp nut
|
| Fixture thickness for clamp nut: |
25.5 mm
|
| Special features: |
Graduation 0.001 mm
|
| Measuring face: |
Carbide-tipped
|
| Mass: |
155 g
|
No technical information is currently available.
No application information is currently available.
