| Digital/Analog: |
Analog
|
| Delivered: |
In a paper box with spanner 200168
|
| Inch-Metric: |
Inch
|
| Range: |
0.5 - 0.5 "
|
| Graduation: |
0,001"
|
| Max. Permissible Error J MPE: |
±0,0001"
|
| Spindle end: |
Spherical (SR4)
|
| Spindle pitch: |
0,5 mm mm
|
| Stem Ø: |
375"
|
| Stem: |
w/ clamp nut
|
| Fixture thickness for clamp nut: |
11.5 mm
|
| Measuring face: |
Carbide tipped (>90 HRA)
|
| Measuring face: |
Carbide tipped (>90 HRA)
|
| Mass: |
60 g
|
No technical information is currently available.
No application information is currently available.
