Description
SS - Product Addons
Select product(s) to see addons appear.
This message only appears in theme editor.Welcome to MQS-Shop, your one-stop online store for metrology products and a UKAS accredited calibration laboratory No. 0373.
| Model: |
SJ-500P
|
| Inch-Metric: |
Metric
|
| Traverse: |
50 mm
|
| Measuring speed: |
0.02 - 5.0 mm/s
|
| Traverse straightness: |
0,2 µm / 50 mm
|
| Range: |
800 µm; 80 µm; 8 µm
(up to 2,4 mm with an optional stylus) |
| Positioning: |
±1.5° (tilting) 30 mm (up/down)
|
Software: |
FORMTRACEPAK |
| Detector measuring force: |
0.75 mN
|
| Stylus tip angle: |
60°
|
| Stylus tip radius: |
2 µm
|
