Weld gauge consists of three components: main scale, glide gauge and multiple-purpose gauge and is
specially used for the measurement of the bevel angle of weldment the height and gap size of all kinds of is
specially used for the measurement of the bevel angle of weldment, the height and gap size of all kinds of weld
seams and the thickness of weldment's plan kings. It is suitable for the detection of the quality of beliers, bridges,
chemistry machines, ships and pressure vessels. It is made of stainless steel.
Thickness of Weldment
Height of
Weld Seam
Gap Size of Weld Seam
Bevel Angle of Weldment
Multiple-purpose Gauge
Weld Gauge
Scale
Surface Height 0-20 0.2
Thickness of Fillet Weld 0-12 0.2
Width 0-45 0.3
Undercut Depth of Welding Seam 0-5 0.1
Bevel Angle of Weldment ?150° 30'
Gap Size 0.5-5 0.1
