Schwenk 30400000 Indicating plug Gauge OD Range 30,1 - 40mm h=3.5 Ø, Sleeve Dimension H=20mm Accuracy=.001-.002mm, Standard Version
Schwenk 30400000 Indicating plug Gauge OD Range 30,1 - 40mm h=3.5 Ø, Sleeve Dimension H=20mm Accuracy=.001-.002mm, Standard Version
Schwenk 30400000 Indicating plug Gauge OD Range 30,1 - 40mm h=3.5 Ø, Sleeve Dimension H=20mm Accuracy=.001-.002mm, Standard Version
Roll over image to zoom in Click on image to zoom
Schwenk 30400000 Indicating plug Gauge OD Range 30,1 - 40mm h=3.5 Ø, Sleeve Dimension H=20mm Accuracy=.001-.002mm, Standard VersionSchwenk 30400000 Indicating plug Gauge OD Range 30,1 - 40mm h=3.5 Ø, Sleeve Dimension H=20mm Accuracy=.001-.002mm, Standard VersionSchwenk 30400000 Indicating plug Gauge OD Range 30,1 - 40mm h=3.5 Ø, Sleeve Dimension H=20mm Accuracy=.001-.002mm, Standard Version

Schwenk 30400000 Indicating plug Gauge OD Range 30,1 - 40mm h=3.5 Ø, Sleeve Dimension H=20mm Accuracy=.001-.002mm, Standard Version

SchwenkSKU: 30400000
Price:
£345.00



Application

For quick comparison measurements of bores during series inspections.
The slightly undersized, ground sleeve is used to guide and centre the plug gauge in the bore.

Execution

  • Cemented carbide measuring contacts and measuring needles (wear-resistant)
  • Plug gauge from dia. 130 mm can be supplied as a cross-shaped sleeves or cross-shaped sleeves with skids
  • Standard version

Advantage

  • Easy to use
  • Minimum measuring times
  • Maximum measuring accuracy
  • Robust and reliable
  • Adapted to the desired bore diameter and tolerance

Brand

SCHWENK

Manufacturer Part Number

30400000

Design of measuring contact

Carbide

Min./max. diameter of measuring range

30.1-40 mm

Measurement travel

0.2 mm

Front size

3.5 mm

Repeat accuracy

1 µm

Sleeve length

20 mm

Connection thread

M11 x 0.75



Please let us know the exact bore tolerance with your order:
Example: measuring sleeve OD No. 304 00000 35 H7
measuring sleeve OD No. 304 00000 35 + 0,15/-0,01
measuring sleeve OD No. 304 00000 34,990/35,005
* nominal Ø 6,1 - 9 mm: h = 6 mm; nominal Ø 9,1 - 12 mm: h = 10 mm
Schwenk 30200000 Indicating plug Gauge OD Range 12,1 - 20mm. h=2.5 Ø, Sleeve Dimension H=15mm Accuracy=.001-.002mm, Standard Version

No technical information is currently available.

No application information is currently available.

No videos or documents are currently available.
