Setting Ring 275mm 177-310

Name: Setting Ring 275mm 177-310
Brand: Mitutoyo
SKU: 177-310
Price: 1862.0 GBP
Availability: InStock

MitutoyoSKU: 177-310

List price: £2,550.00 Offer price: £1,862.00 Excluding VAT

Quantity:

Optional Services

UKAS Accredited Calibration +£25.00 Add UKAS-accredited calibration with certificate.
Please allow an additional 7–10 working days for calibration.

Professional Laser Marking by Automator Lasers Price is per item. Add your Gauge ID, asset number or company name.
£10.00 per item

Number of items to be laser marked

Overview Technical Information Applications Videos & Documents

177-310 Mitutoyo Steel Setting Ring – 275mm

Type: B
Nominal Size: 275m
Tolerance Between Nominal and Actual Diameter: +/- .020mm
Thickness: 38.1mm/25.4mm
Uncertainty of Marked Diameter Value: +/- .0025mm
Roundness/Cylindricity: .003mm
Distance from the Side Face (H): 5.3mm
Side of Warranted Calibration Surface (K): 27.7mm
Outside Diameter: 413mm
E Dimension for Type B: 321mm

No technical information is currently available.

No application information is currently available.

Product Documents

Product Document Setting Ring 275mm 177-310 Click to open the PDF document
