Spline Micrometer 0-1", 0,0001", 3mm Measuring Face 111-166

Roll over image to zoom in Click on image to zoom

Spline Micrometer 0-1", 0,0001", 3mm Measuring Face 111-166

Name: Spline Micrometer 0-1", 0,0001", 3mm Measuring Face 111-166
Brand: Mitutoyo
SKU: 111-166
Price: 134.0 GBP
Availability: InStock

MitutoyoSKU: 111-166

- Free UK delivery on orders over £100

- Fast dispatch from UK stock (over 25,000 gauges in stock)

- UKAS calibration available on all gauges (allow 7 days for calibration)

Price:

£134.00 £184.00

Quantity:

All prices exclude VAT, which will be added at checkout.

Spline Micrometer with 3mm Measuring Face

A Mitutoyo non-digital micrometer provided with a spindle and anvil reduced in diameter to enable measurement within slotted features, such as keyways. A ratchet stop guarantees repeatable measurement. High resolution provided by a vernier scale on sleeve.

Product Information
Part Number	111-166
Measuring Ranges	0-1"
Graduation	.0001"
Accuracy	+/-.00008"
Unit of Measurement	Inch
Display Type	Analogue
Measuring Force	5-10N
Type	Spline
Constant Force Device	Ratchet Stop
Manufacturer	Mitutoyo

Digital/Analog:	Analog
Delivered:	Including box, spanner
Inch-Metric:	Inch
Range:	0 - 1 "
Graduation:	0,0001"
Max. Permissible Error J MPE:	±0,00015"
Flatness:	0,000012"
Parallelism:	0,00008"
Measuring face:	Carbide-tipped, micro-lap finish, stepped
Anvil / Spindle:	Type A, D=3 mm
Measuring spindle:	With spindle lock, ø6,35 mm, spindle pitch 0,5 mm
Scale:	Thimble and sleeve satin chrome finish, ø18 mm
Measuring force:	5 - 10 N
Mass:	205 g
