Starrett 714JFLZ LCD Interchangeable Anvil Micrometer, Friction Thimble, Lock Nut, 500-600MM/20-24"

Roll over image to zoom in Click on image to zoom

Starrett 714JFLZ LCD Interchangeable Anvil Micrometer, Friction Thimble, Lock Nut, 500-600MM/20-24"

Name: Starrett 714JFLZ LCD Interchangeable Anvil Micrometer, Friction Thimble, Lock Nut, 500-600MM/20-24"
Brand: Starrett
SKU: 714JFLZ
Price: 995.0 GBP
Availability: InStock

StarrettSKU: 714JFLZ

- Free UK delivery on orders over £100

- Fast dispatch from UK stock (over 25,000 gauges in stock)

- UKAS calibration available on all gauges (allow 7 days for calibration)

Price:

£995.00 £1,725.00

Quantity:

All prices exclude VAT, which will be added at checkout.

Specifications
- Made in America: Yes
- Micrometer Type: Electronic Interchangeable Anvil Outside Micrometer
- Range 500-600mm/20-24"
- Resolution (in): .0001"
- Resolution (mm): 0.001mm
- Anvil/Spindle Material: Steel
- Anvil Type: Flat
- Spindle Type: Flat
- Accuracy (mm): +/-.01mm/.0005"
Features
- Balanced frame and thimble design ensure easy handling and better readability
- Compatible with Starrett Datasure Wireless Data Collection Systems
- Advanced sleeve design with staggered lines and distinct figures for precise and easy readability
- Conventional inch or millimeter graduations standard
- Quick and easy adjustment
- Large, easy-to-read, high-contrast LCD digital readout
- Starrett No-glare satin chrome finish on thimble and sleeve minimizes annoying surface glare under bright lights indoors or filters out UV light
- No-glare black wrinkle finish on frame
- Hard and stable one-piece friction thimble permits one-hand operation of micrometer and uniform contact pressure
- Rigid and stable special cast iron frame with appropriate perforations for lightness and ribbed for strength and stability
- Ability to zero tool at any position as well as retain and return to the true zero reading of the micrometer
- Ring-type knurled lock nut for quick and sure locking
- Micro-lapped carbide measuring faces
- Interchangeable anvils
- One 3-volt battery included for extended usage
- Automatic OFF
- Measurement HOLD button
- SPC output capability
- Inch/millimeter metric conversion provides simple, universal, standardized unit of measurement at any position
- PRESET button to install any reading at any position

Product Information
Part Number	714JFLZ
Measuring Ranges	500-600mm/20-24"
Resolution	.001mm/.0001"
Accuracy	+/-.01mm
Unit of Measurement	Metric Inch
Display Type	Digital
Type	Interchangeable Anvil
Constant Force Device	Ratchet Stop
Flatness	.000024"
Parallelism	.00008"
Manufacturer	Starrett
