Large digital readout is easy to read, reducing errors
Attractive black wrinkle finish on frame
Starrett no-glare satin chrome finish on thimble and sleeve
Ring-type knurled lock nut
Extremely hard and stable one-piece spindle (the heart of our accuracy)
Auto OFF after 30 minutes of nonuse
Inch/millimeter conversion
Measurement HOLD button
Ability to zero tool at any position
Ability to retain and return to the true zero reading of the micrometer
PRESET button to install any reading at any position
RS232 data output port
| Resolution | 0.001 mm/.00005" |
|---|---|
| Accuracy | ± 0.003 mm |
| Stem diameter | 12.7 mm |
| Stem | Plain |
| Spindle face | Flat (carbide tip) |
| Range | 0 - 25 mm/0-1" |
| Type | Micrometer head |
