Lever-Type Dial Indicator 0.8mm 0.01mm Ø28mm 01810005
Roll over image to zoom in Click on image to zoom
Lever-Type Dial Indicator 0.8mm 0.01mm Ø28mm 01810005

Lever-Type Dial Indicator 0.8mm 0.01mm Ø28mm 01810005

TesaSKU: 01810005
List price: £163.00 Offer price: £97.80 Excluding VAT

Optional Services

Add UKAS-accredited calibration with certificate.
Please allow an additional 7–10 working days for calibration.
Price is per item. Add your Gauge ID, asset number or company name.
£10.00 per item

TESATAST Lever-Type Dial Indicator 0.8mm Travel 0.01mm Resolution Ø28mm 01810005


Specification

Measuring force Low measuring force
Units mm
Standard DIN 2270 / EN ISO 9493
Material Housing: metal Ball inserts: tungsten carbide
Dimensions Insert thread: M1,4
Dial Rotating dial
Particular characteristic(s) Integrated shockproof system
Included in delivery

Lever-type dial test indicator with mounted ball insert Ø 2 mm Wrench for insert mounting Rigid stem Ø 8 mm User manual Declaration of conformity

  • type Horizontal Type
  • range 0.8mm
  • display type Non-Digital
  • graduations 0.01mm
  • bezel dia 28mm
  • measuring force 0.15 N
  • measuring units Metric
  • scale 0-0.4-0
  • contact point thread M1.4
  • repeatability limit 3 µm
  • brandTesa

No technical information is currently available.

No application information is currently available.

Product Documents

Product Document Lever-Type Dial Indicator 0.8mm 0.01mm Ø28mm 01810005 Click to open the PDF document
