| Standard | Manufacturer’s standard | |
| Measuring range | 25 mm | |
| Reversible reading | 0.001 mm | |
| Reversible reading | 0.00005 in | |
| Reversible reading | mm / inch | |
| Error limit | 0.005 mm | |
| Interface | RS232 interface; USB interface | |
| Gauging force | < 2 N | |
| Clamping shank ? h6 | 8 mm | |
| Measurement technology | digital | |
| Body ? | 57 mm | |
| Thickness of housing | 33.4 mm | |
| Loop on the back of the dial indicator | no | |
| Power supply | Battery-powered | |
| Number of batteries contained | 1 |
