Tube Micrometer, Spherical Anvil/Spindle 0-15mm, Carbide-tipped 115-201

Roll over image to zoom in Click on image to zoom

Tube Micrometer, Spherical Anvil/Spindle 0-15mm, Carbide-tipped 115-201

Name: Tube Micrometer, Spherical Anvil/Spindle 0-15mm, Carbide-tipped 115-201
Brand: Mitutoyo
SKU: 115-201
Price: 112.0 GBP
Availability: InStock

MitutoyoSKU: 115-201

- Free UK delivery on orders over £100

- Fast dispatch from UK stock (over 25,000 gauges in stock)

- UKAS calibration available on all gauges (allow 7 days for calibration)

Price:

£112.00 £153.00

Quantity:

All prices exclude VAT, which will be added at checkout.

Mitutoyo; Tube Micrometer

This Tube Micrometer allows you to measure curved surfaces such as the wall thickness of tubes, bearings and rings.

Customer Support

Contact our customer support team via email or call our hotline number

Phone - 02476 644661

Secure payments

We offer multiple secure payment options

Product Information
Part Number	115-201
Measuring Ranges	0-15mm
Graduation	.01mm
Accuracy	+/_.003mm
Unit of Measurement	Metric
Measuring Force	5-10N
Type	Tube
Constant Force Device	Ratchet Stop
Manufacturer	Mitutoyo

Digital/Analog:	Analog
Delivered:	Including box, spanner
Inch-Metric:	Metric
Range:	0 - 15 mm
Graduation:	0,01 mm
Max. Permissible Error J MPE:	±3 µm
Measuring face:	Spindle and anvil: carbide-tipped, micro-lap finish (115-1xx, 115-2xx) spindle: carbide-tipped, micro-lap finish anvil: hardened steel (115-3xx)
Anvil / Spindle:	Spherical D=1 mm and R=1 mm/spherical R=4 mm spindle
Measuring spindle:	With spindle lock, ø6,35 mm, spindle pitch 0,5 mm
Scale:	Thimble and sleeve satin chrome finish, ø18 mm
Measuring force:	3 - 8 N
Delivered:	Including box, setting standard (from 25 mm upward), key
