Product Overview
The #1185 6-Lobe (TX) Final Inspection Gage is designed for finished product verification of internal 6-Lobe recess head screws where final acceptance and dimensional consistency must be confirmed after manufacturing and finishing operations. This gage supports the last critical inspection step before parts move to shipment, assembly, or customer release.
In practical use, final inspection gaging helps verify that the recess remains acceptable after coating, plating, or other downstream processes that can influence usable form. It gives quality teams a repeatable way to confirm finished part readiness and maintain confidence in outgoing product.
Universal Punch designs precision gaging systems for demanding manufacturing environments where reliability, repeatability, and professional inspection performance are essential.
What This Gauge Checks
- Finished internal 6-Lobe recess acceptance
- Post-process dimensional conformance
- Final inspection consistency before shipment
- Recess usability after manufacturing and finishing
- Quality verification for outgoing product
-
Drive Size Part Number Reference Number T4 1185-04 4-TXI-901 T5 1185-05 5-TXI-901 T6 1185-06 6-TXI-901 T7 1185-07 7-TXI-901 T8 1185-08 8-TXI-901 T9 1185-09 9-TXI-901 T10 1185-10 10-TXI-901 T15 1185-15 15-TXI-901 T20 1185-20 20-TXI-901 T25 1185-25 25-TXI-901 T27 1185-27 27-TXI-901 T30 1185-30 30-TXI-901 T40 1185-40 40-TXI-901 T45 1185-45 45-TXI-901 T50 1185-50 50-TXI-901 T55 1185-55 55-TXI-901 T60 1185-60 60-TXI-901 T70 1185-70 70-TXI-901 T80 1185-80 80-TXI-901 T90 1185-90 90-TXI-901 T100 1185-100 100-TXI-901 Standards, Quality, and Traceability
Universal Punch manufactures gaging products for precision manufacturing environments where final inspection accuracy, repeatability, and outgoing quality confidence are critical. The #1185 Final Inspection Gage is referenced to TMQ-811, TMF-811, TXF-811, and TXQ-811 for internal (TX) recess head screws.
Gage probes are heat treated, thermally stabilized, and surface treated to maximize wear life. Long-form calibration certificates provide dimensions and tolerances to specified standards and are traceable to NIST, supporting controlled final inspection documentation and dependable long-term use.
Typical Applications
- Finished fastener inspection
- Outgoing quality verification before shipment
- Post-plating and post-process acceptance checks
- Aerospace and defense fastener programs
- Automotive, medical device, and industrial precision assembly operations
Options and Ordering Notes
- Specify tamper-proof style for sizes #6 through #45 if required
- Long-form calibration certificates support traceable inspection documentation
- Contact Universal Punch for application guidance and quote support
- Ideal for final acceptance inspection of finished internal 6-Lobe fasteners
Need More Than a Standard Page?
This layout is ideal for a scalable WordPress product system. It supports images, embedded video, technical data, ordering tables, and strong quote-driven calls to action while keeping the page clean, modern, and easy to scan.
Suggested related products: #1180 Penetration Gage, #1181 GO Penetration Gage, #1182 No-Go Fallaway Gage, #1184 GO / NO-GO Gage.
