The #9475 Digital Length Gaging Fixtures from Universal Punch Corp. are designed to support accurate and repeatable measurement of fastener length and protrusion using digital inspection systems. These fixture platforms provide stable part positioning and consistent alignment, allowing operators to perform length measurements quickly and reliably in production and quality environments.
Engineered for modern inspection workflows, the #9475 fixture system supports digital indicators and electronic measurement devices, enabling efficient data collection and improved inspection repeatability across high-volume manufacturing and receiving inspection operations.
Digital length measurement fixture system
Supports stable part positioning and alignment
Designed for repeatable digital inspection workflows
Production and quality control use
Compatible with Universal Punch gaging systems
Product Overview
The #9475 Digital Length Gaging Fixtures are engineered for applications where accurate fastener length or protrusion measurement must be performed efficiently and consistently. By holding the part securely and maintaining consistent alignment with the measuring device, the fixture helps improve inspection reliability and measurement repeatability.
When paired with digital indicators or electronic measurement systems, this fixture platform allows operators to capture precise measurement data quickly, making it well suited for environments that require consistent inspection documentation and statistical process control workflows.
Universal Punch designs fixture systems for demanding manufacturing environments where dimensional accuracy, repeatability, and inspection efficiency are essential.
What This Fixture Supports
- Stable support for digital length measurement inspection
- Improved repeatability during dimensional verification
- Reduced setup variation between operators
- Controlled positioning of fasteners and precision components
- Production and receiving inspection workflows
