Mahr 4333900 Inch Compramess Mechanical Dial Comparators Accuracy: DIN 879-1 Graduation: .0001'' Model: 1004 Z Compramess Range: +/- .005'' Force 1N
Mahr 4333900 Inch Compramess Mechanical Dial Comparators Accuracy: DIN 879-1 Graduation: .0001'' Model: 1004 Z Compramess Range: +/- .005'' Force 1N
Roll over image to zoom in Click on image to zoom
Mahr 4333900 Inch Compramess Mechanical Dial Comparators Accuracy: DIN 879-1 Graduation: .0001'' Model: 1004 Z Compramess Range: +/- .005'' Force 1NMahr 4333900 Inch Compramess Mechanical Dial Comparators Accuracy: DIN 879-1 Graduation: .0001'' Model: 1004 Z Compramess Range: +/- .005'' Force 1N

Mahr 4333900 Inch Compramess Mechanical Dial Comparators Accuracy: DIN 879-1 Graduation: .0001'' Model: 1004 Z Compramess Range: +/- .005'' Force 1N

MahrSKU: 4333900
List price: £220.95 Offer price: £186.70 Excluding VAT

MarTest 1004Z DTI 4333900

Specification

  • Product type 1004 Z
  • Measuring range inches ± .0050"
  • Standard Factory standard
  • Graduation value inches 0.0001 inch
  • Figure on dial face .005"-0-.005"
  • Error limit Ge in inches (text) .0001"
  • Error limit Gges in inches (text) .00012"
  • Error limit Gt in inches (text) .00005"
  • Measuring value hysteresis fu (inches) 3.0E-5 inch
  • Repeatability fw (inches) 3.0E-5 inch
  • Measuring force 1 N
  • Scale diameter 50 mm

No technical information is currently available.

No application information is currently available.

No videos or documents are currently available.
