MarTest 800SDZ Lever-Type DTI 4308950
Specification
Product type 800 SDZ
- Measuring range: inches ± .004"
- Resolution: 0.0001"
- Standard: Factory standard
- Figure on dial face 4-0-4 (White Dial)
- Pointer rotation (inches) .008"
- Deviation range fe (inches) .00012"
- Total deviation range fges (inches) .00016"
- Measuring value hysteresis fu (inches) .00008"
- Partial measuring range ft (inches) .00008"
- Repeatability fw (inches) .0001"
- Measuring force 0.15 N
- Scale diameter (inches) 1.1"
