Bowers XT Analogue Bore Gauge Set 100-150mm SXTA7W (W/O Setting Rings)

Roll over image to zoom in Click on image to zoom

Bowers XT Analogue Bore Gauge Set 100-150mm SXTA7W (W/O Setting Rings)

Name: Bowers XT Analogue Bore Gauge Set 100-150mm SXTA7W (W/O Setting Rings)
Brand: Bowers
SKU: SXTA7W
Price: 1011.0 GBP
Availability: InStock

BowersSKU: SXTA7W

- Free UK delivery on orders over £100

- Fast dispatch from UK stock (over 25,000 gauges in stock)

- UKAS calibration available on all gauges (allow 7 days for calibration)

Price:

£1,011.00 £1,218.50

Quantity:

All prices exclude VAT, which will be added at checkout.

BOWERS XT ANALOGUE BORE GAUGE SET METRIC

The extended mechanical travel of these advanced two or three point gauges ensures that exchanging measuring anvils is now unnecessary. Their wide application range, 2-300mm, rugged construction and easy read scale, ensure both accuracy and ease of use. XT measuring heads are supplied with UKAS certification.

Range 2-300mm (0.080"-12")
2-6mm 2 point / 6-300mm 3 point measurement
Graduation 2-6mm: 0.001mm, 6-300mm: 0.005mm
Tungsten carbide measuring faces on all 3-point heads from 12.5mm
Blind bore measurement from 2mm-6mm and above 12.5mm (0.500")
Extensions available above 6mm for deep hole measurement
Ratchet stop to ensure consistent measurement
Setting rings included with individual instruments and sets
UKAS certificate supplied as standard with all XT mechanical micrometers
Serial number on all gauges
Bore gauges manufactured according to DIN 863, part 4
Supplied in fitted case

All images are for representation only.

Product Information
Part Number	SXTA7W
Measuring Ranges	100-150mm
Resolution	0.005mm
Display Type	Analogue
