Baker (Mercer Style) Plunger indicator K02, Range 10mm, Graduation .01mm, Reading 0-100

Roll over image to zoom in Click on image to zoom

Baker (Mercer Style) Plunger indicator K02, Range 10mm, Graduation .01mm, Reading 0-100

Name: Baker (Mercer Style) Plunger indicator K02, Range 10mm, Graduation .01mm, Reading 0-100
Brand: Baker
SKU: K02
Price: 20.0 GBP
Availability: InStock

BakerSKU: K02

- Free UK delivery on orders over £100

- Fast dispatch from UK stock (over 25,000 gauges in stock)

- UKAS calibration available on all gauges (allow 7 days for calibration)

Price:

£20.00 £39.00

Quantity:

All prices exclude VAT, which will be added at checkout.

- A sturdy and robust dial gauge.
- Fitted with special brass bush bearings.
- Supplied with tolerance pointers.
- Strong and smooth metal bezel.
- Rigid, metal case.
- Aesthetically appealing protective top cap.
- Tungsten carbide ball anvil.
- Metric gauges conform to IS2092-1983 and for the European market to DIN878-1983.
- Inch gauges conform to ASME B89.1.10M-2001.
- Each gauge carries a calibration certificate giving actual values.
- Wide range of dial gauges in various ranges and readings available.
- Special dial gauges for OEMs also manufactured on request.
- Complete spares and after sales service available.
Baker (Mercer Style) Plunger indicator J72, Range 50mm, Graduation .01mm, Reading 0-100 Face 88mm

Product Information
Part Number	K02
Measuring Ranges	10mm
Graduation	.01mm
Accuracy	.015mm
Unit of Measurement	Metric
Measuring Force	≤1.5N
Repeatability	.003mm
Dial Reading	0-100
Dial Face Size Ø	57mm
Hysteresis	.003mm
Stem	8mm
Stem Diameter	8mm
Back	Centre Lug Back
Range Per Rev	1mm
Manufacturer	Mitutoyo

Digital/Analog:	Analog
Inch-Metric:	Metric
Functions:	ISO type
Delivered:	With certificate of inspection
Range:	50 mm
Range per rev.:	1 mm
Dial reading:	0-100
Graduation:	0.01 mm
Measuring force:	3 N
MPE any 1/10 revolution:	10 µm
MPE any 1/2 revolution:	12 µm
MPE any 1 revolution:	15 µm
Over all measuring range accuracy:	30 µm
H MPE (Hysteresis):	8µm
R MPE (Repeatability):	5 µm
Mass:	200 g
Stem:	8 mm
Contact point:	Carbide tipped, thread: M 2.5 x 0.45 mm
