Mahr Digital Comparator Millimess 1003 4334000
Mechanical dial comparator Millimess 1003
DIN 879-1
- Large, high contrast dial face
- Adjustable tolerance markers
- Lockable fine adjustment screw
- Shockproof movement
- Mounting shank and measuring spindle are both made of hardened stainless steel
- Measuring spindle is mounted in a high precision ball guide for minimal hysteresis
- Resistant to lateral forces (side play) acting on the measuring spindle
- Maximum sensitivity and accuracy are ensured by the jeweled movement in conjunction with the precision gears and pinions
- Box type protective housing
- Constant measuring force
- Measuring spindle can be retracted with either a screw in cable release or with a lifting knob
Dial color - Yellow
Measuring range mm - ± 50 µm
Graduation value µm - 1 µm
Measuring force - 1 N
Package contains - Test certificate, Case
